PNC550 PoC Mobile Computer
Push-to-Talk over Cellular Handheld Smart Device
The Hytera PNC550 is a Push-to-Talk over Cellular (PoC) radio and handheld smart device designed for nationwide business operations and remote workforce communications. The PNC550 combines the advantages of a compact mobile computer with ruggedness, enhanced audio quality, and instant Push-to-Talk group communications of a professional PoC device. It supports Android business apps to provide unified operations and communications in a single device.
Key Features
NATIONWIDE COVERAGE
National wide-area communication with mobile 4G/LTE connectivity
BUILT-IN WI-FI
Built-in Wi-Fi supports in-building communications with seamless switching to LTE networks when outside Wi-Fi range
INSTANT GROUP AND INDIVIDUAL CALLING
Push-to-Talk button initiates instant voice or video calls to groups or individuals
HIGH-DEFINITION LIVE VIDEO
Features a 13-megapixel rear camera with fash and an 8-megapixel front camera
HIGH-QUALITY AUDIO
Dual microphones with digital noise suppression and high-volume speaker for industry leading voice quality in loud environments
DUAL SIM
Dual SIM cards provide flexibility for two network data plans
GPS POSITIONING
GPS enables real-time tracking and positioning for the Hytera HyTalk Dispatch application
ERGONOMIC DESIGN
Lightweight and ergonomic design with easy-access buttons enables comfortable one-hand operation
5 INCH GORILLA GLASS DISPLAY
5-inch, multi-touch Gorilla Glass display with 1280×720 WVGA resolution
ANDROID OPERATING SYSTEM
Supports popular Android business apps for unified operations and communications
RUGGED AND DURABLE
Compliant with MIL-STD-810-G for shock and vibration
SAFETY FEATURES
One-touch Emergency button enables one-touch emergency calls to dispatcher and other PoC devices
LONG-LIFE BATTERY
Powerful 4,000mAh Lithium-Ion Polymer battery delivers up to 24 hours of operation
TEXT MESSAGING
Send, receive, and view text messages between dispatcher and other Hytera PoC devices
Technical Specifications
| LTE | FDD LTE: B1/B3/B5/B7/B8/B20/B26/827/B28 |
| WCDMA | B1/B3/B5/B8 |
| GSM | 850/950/1800/1900MHz |
| Wi-Fi | 2.4GHz 802.11b/g/n |
| Bluetooth | BT 4.1 |
| Positioning System | GPS |
| Near Field Communications | NFC Supported |
| Audio Formats | MP3, aacPlus, eAAC, AMR-NB, AMR-VB, G.711 Windows Media Audio 9/10/Pro |
| Video and Image Formats | H.263, P0, H.264, H.265, PB/MO/HP, MPEG-4,SP/ASP, DivX, VP8, VP9, JPG, BMP, PNG, WebP |
| Audio Power Output | Maximum 2W |
| Microphone | 2 (Dual mic noise suppression) |
| Operating Temperature | -4F to +140F (-20C to +60C) |
| Storage Temperature | -22F to +158F (-30C to +70C) |
| ESD | IEC 61000-4-2 (Level 4) ±8kV Contact, ±12kV Air |
| Dust and Water Ingress | IP68 Standard |
| Humidity | Per MIL-STD-810 C/D/E/F/G Standard |
| Shock and Vibration | Per MIL-STD-810 C/D/E/F/G Standard |
| Battery | 4000mAh (Li-Ion Polymer) |
| Battery Life (5/5/90) | Up to 24 Hours |
| Weight | 8.8oz (250g) |
| Dimensions (H x W x D) | 6 1/8” x 3” x 1/2” (156 x 76 x 14mm) |
| Operating System | Android 8.1 |
| Memory | 3GB RAM + 32GB ROM, Expandable to 64GB |
| Card Slots | 2x Nano-SIM, 1x MicroSD |
| Display | 5” Gorilla Glass 1280 x 720 WVGA Supports Capacitive Touch, Multi-Touch, Wet Touch, and Glove Touch |
| Camera | 13MP Front Facing, 8MP Rear Facing |
| Ports | USB 2.0 Type Q Charger Interface 3.5mm Audio Interface |
| Operating Voltage | 3.7V |
| Physical Interface Buttons | 1x Push-to-Talk, 2x Volume (+/-), 1x Emergency, 1x Power |
| Sensors | Gravity, Compass, Proximity, Light |
