PNC380

PNC380 PoC Radio

PTT over Cellular Radio

radio

The push-to-talk (PTI) communication has been proven to be efficient and reliable in business world for decades. With the rapid evolution of mobile

Get a Quote

Key Features

Stay connected, stay informed icon

Stay connected, stay informed

Leveraging the broad coverage of 2G, 3G, 4G, and WLAN networks of various carriers, the PNC380 delivers seamless communications across your country. Talk to groups or individuals instantly at a push of the PTT button, or make a telephone call with the full keypad at your will.

4,000 mAh – lasts all day long icon

4,000 mAh – lasts all day long

The 4,000 mAh Li-ion battery offers over 24 hours of talk and standby time on a 5-5-90 duty cycle, and can be charged through the radio's Micro USB port.

4G live video icon

4G live video

Equipped with a 5 MP rear camera, the radio allows you to feed the on-site videos to the dispatcher or supervisor in real time over 4G network, improving situational awareness and facilitating decision-making.

Enhanced ergonomic design icon

Enhanced ergonomic design

Compact and ergonomic design, paired with the deliberate side key layout, makes the one-hand operation easy and comfortable. The anti-slip textured case ensures firm grip even in moist conditions.

Positioning icon

Positioning

The PNC380 provides positioning services by using GPS, GLONASS, and BDS in combination, together with the assisted GPS technology.

IP67 and MIL-STD-810G icon

IP67 and MIL-STD-810G

Certified with IP67 rating, the radio is fully protected from dust and is water-proof up to 1 meter for 30 minutes. The radio also meets the MIL-STD-810G standard to withstand 1.5-meter drop.

Loud and clear audio icon

Loud and clear audio

Adopting the dual-mic noise reduction technology, the radio always picks up the right voice from noisy background. The advanced acoustics design substantially elevates sound loudness and sharpness.

Technical Specifications

FrequencyAsia, Europe, Middle East, and Africa (B8): GSM: 850 / 900 / 1800 / 1900; CDMA: BCO; WCDMA: B1/B3/B5/B8; TD-SCDMA: B34/B39; TDD-LTE: B38/B39/B40/B41; FDD-LTE: B1/B3/B5/B7/B8/B18/B19/B20/B26/B27/B28
Screen size2 inches
Screen resolution320x240
KeypadFull keypad
Dimensions (H x W x D)145.1 mm x 60 mm x 26.1 mm
Weight208 g (with battery and antenna)
Ingress ProtectionIP67
Drop resistance1.2 m
RAM512MB / 1GB
ROM4GB / 8GB
Extended memoryMicro SD/TF card: Maximum 32 GB
Capacity4000 mAh, replaceable
Battery life24 h (5-5-90 duty cycle)
Operating voltage3.85V
WLAN2.4 GHz and 5 GHz
BTBT 4.1
NFCSupported
SystemsGPS/GLONASS/BDS/AGPS
Rear camera5 MP
FlashSupported
Recording720P (1280x720) 30 FPS
File formatMPEG-4 (.mp4), 3GPP (.3gp)
CodecVP8, H.264 (BP/MP/HP), MPEG-4 (SP/ASP), H.263 (HEVC)
File formatJPEG (.jpg), PNG (.png)
File formatMPEG (.m4a), 3GPP (.3gp)
